W-UHPH

TUBE: |
Polyoxymethylene |
REINFORCEMENT: |
Six spiral layers of maximum tensile steel wire |
COVER: |
1st: Polyamide; 2nd: Polyurethane, abrasion resistant. |
APPLICATION: |
Construction and shipbuilding industry (for very high pressure lances with > 300MPa) Hydrodemolition and removal of accumulated dirt and materials. For working pressure up to 280 MPa (40.600psi) |
TEMPERATURE: |
-10° C up to + 70° C |
HOSE SIZE |
WORKING PRESSURE |
BURST PRESSURE |
TEST PRESSURE |
BEND RADIUS |
WEIGHT (APPROX) |
||||
DN |
INCH |
BAR |
PSI |
BAR |
PSI |
BAR |
PSI |
mm |
KG/m |
8 |
1/2 |
1500 |
21750 |
4500 |
65250 |
3000 |
43500 |
320 |
1.5 |
1BAR=1PASCAL |
1BAR= 14.5 PSI |
1Mpa=10BAR |
